Description
This hub is constructed with 5 studs on a 4-1/2 inch bolt pattern. The trailer hub is rated at 1,750 lb. capacity. This trailer wheel hub assembly comes with both an inner and outer race, also known as a cup. Additionally, the inner and outer bearings, seal, bearing lube cap, cap plug, and 5 nuts are included.
Specifications
- Trailer Hub Assembly
- Bearing included
- 5 studs, 4-1/2 in. bolt pattern
- 1,750 lb. capacity
- When measuring through the center of the hub,
this hub is 4-1/16″ tall from edge to edge - Use rim, asc 30539A
Replacement Parts
- 17932 – L-44649 Tapered Roller Bearing
- 17943 – L-68149 Tapered Roller Cone
- 17933 – L-44610 Tapered Roller Cup
- 17942 – L-68111 Tapered Roller Cup
- 25687 – Seal
- 31235 – Stud for 1206 Hub Assembly
- 25686 – Trailer Axle Spindle Assembly, 10″ L, 1,750 lb. Capacity
- 25685 – Spindle Assembly, 7-1/2″ 1750 lb. Capacity
- 24126 – Bearing Buddy®, 1980A (not included)
- Replacement bearing kit use ASC 36173
